B016, CL03, EE03, L015?? Have you ever wanted to know what the modification numbers after the standard DEUTSCH part numbers mean? This list of DEUTSCH connector modifications will help! It covers all of the DEUTSCH industrial connector series.
[table caption=”Modification List” width=”100%” class=”table-striped” colwidth=”20|50|500″ colalign=”left|left|left|”]
Mod,Series,Description
A,,
A004,DRC,Receptacle with molded-in PCB pins‚ 24 and 40 way
A006,DRC,Receptacle with molded-in PCB pins 40 way‚ #40 pin removed
,,
B,,
B009,HD10,Receptacle with raised key removed from front of flange‚ no rear threads
B010,HD10,Plug with coupling ring added
B016,DT‚DT13‚15,Receptacle has extended shell and enhanced keys‚ plug has enhanced seal retention (P012) 12 way
B019,HD30,Custom snap ring mount
B022,HD10,Receptacle with D-hole panel mount rear threads‚ J1939‚ black
B025,HD10,Receptacle with D-hole panel mount‚ no rear threads‚ black
B026,DTMF,PCB receptacle with alternate keying requires plugs with WM-12S-B026 wedgelocks
B028,DT15,5 P.S.I rating
,,
BE,,
BE02,DT,Receptacle with extended shell and enhanced keys (B016)‚ end cap
BE03,DT,Receptacle with extended shell and enhanced keys (B016)‚ end cap‚ black
BE04,DT,Receptacle with extended shell and enhanced keys (B016)‚ end cap‚ reduced diameter seals (E seal)‚ black
BE05,DT,Receptacle with extended shell and enhanced keys (B016)‚end cap‚ sealed flange‚ reduced diameter seals (E seal)‚ threaded stainless steel flange inserts
,,
BL,,
BL04,DT,Receptacle with extended shell and enhanced keys (B016)‚ welded flange
BL08,DT,Receptacle with extended shell and enhanced keys (B016)‚ welded flange‚ black
BL10,DT,Receptacle with extended shell and enhanced keys (B016)‚ sealed flange‚ reduced diameter seals (E seal)‚ shrink boot adapter‚ threaded stainless steel flange inserts
BL11,DT,Receptacle with extended shell and enhanced keys (B016)‚ sealed flange‚ reduced diameter seals (E seal)‚ end cap‚ threaded stainless steel flange inserts
,,
BP,,
BP03,HD10,Receptacle with D-hole panel mount‚ J1939 Type II‚ green
,,
C,,
C003,HDN,Standard cavity marking identification
C008,DT,Cavity blocked (C)
C012,HD30,Cavities blocked (J‚ P)
C015,DT‚ DTP,Reduced diameter seals (E seal)
C016,HD10,Cavities blocked (H‚ J) – HD10 Series 9 way
C017,DT‚ DTM‚ DTP,Solid rear grommet
C018,HD30,Cavities blocked (11‚ 18‚ 19)‚ N‚E seal options
C019,HD30,Cavities blocked (1‚ 2‚ 8‚ 9)‚ N‚E seal options
C020,HD30,Cavities blocked (A‚ D)‚ N‚E seal options
C021,HD30,Cavities blocked (A‚ B‚ C‚ D)
C022,HD30,Cavities blocked (A‚ D‚ J‚ M)‚ with reduced diameter seals (E seal)
C024,HD10,Cavities blocked (B‚ C‚ D)
C026,DRC,Cavities blocked‚ 50 way
C030,HD30‚ HDP20,Four size 16 cavities blocked (1‚ 2‚ 5‚ 6)
C038,HD30‚ HDP20,Three size 4‚ four size 16‚ requires special size 4 AWG contacts
C041,HDP20,Receptacle with diagnostic keying
,,
CE,,
CE01,DT,Reduced diameter seals (E seal)‚ end cap
CE02,DT‚ DTP,Reduced diameter seals (E seal)‚ black
CE03,DT,Reduced diameter seals (E seal)‚ end cap‚ black
CE04,DT,Reduced diameter seals (E seal)‚ shrink boot adapter
CE05,DT,Plug with reduced diameter seals (E seal)‚ enhanced seal retention (P012)‚ end cap
CE06,DT,Plug with reduced diameter seals (E seal)‚ enhanced seal retention (P012)
CE07,DT,Receptacle with extended shell and enhanced keys (B016)‚ reduced diameter seals (E seal)‚ end cap
CE08,DT,Receptacle with extended shell and enhanced keys (B016)‚ reduced diameter seals (E seal)
CE09,DT,Reduced diameter seals (E seal)‚ shrink boot adapter‚ black
CE10,DT,Plug with reduced diameter seals (E seal)‚ enhanced seal retention (P012)‚ black
CE11,DT,Plug with reduced diameter seals (E seal)‚ enhanced seal retention (P012)‚ end cap‚ black
CE12,DT,Plug with reduced diameter seals (E seal)‚ enhanced seal retention (P012)‚ shrink boot adapter‚ black
CE13,DT,Plug with reduced diameter seals (E seal)‚ enhanced seal retention (P012)‚ shrink boot adapter
CE14,DT,Plug with reduced diameter seals (E seal)‚ enhanced seal retention (P012)‚ latch guard end cap‚ black
,,
CL,,
CL01,HD30,Cavities blocked (J‚ Q‚ R‚ S‚ X)‚ adapter for cable clamp (072)
CL03,DT,Reduced diameter seals (E seal)‚ welded flange
CL07,DT,Reduced diameter seals (E seal)‚ sealed flange‚ shrink boot adapter
CL08,DT,Reduced diameter seals (E seal)‚ welded flange‚ end cap‚ disabled latch
CL09,DT,Reduced diameter seals (E seal)‚ sealed flange‚ end cap‚ black
CL15,DT,Reduced diameter seals (E seal)‚ welded flange‚ black
CL20,HDP20,Plug with diagnostic keying
,,
CG,,
CG01,DRC,5mm threaded insert with silver plating‚ molded-in contacts‚ outside rows gold
,,
CP,,
CP01,DT,All cavities plugged‚ enhanced seal retention (P012)‚ end cap
,,
E,,
E003,DT‚ DTHD‚ DTM‚ DTP,End cap
E004,DT‚ DTM‚ DTP‚ HD10,Black
E005,DT‚ DTM‚ DTP,Black‚ end cap
E007,DTM,Shrink boot adapter
E008,DT,Shrink boot adapter
E009,DRC,24 way and 40 way receptacle‚ B keys‚ housing is gray‚ flange is black
E016,EEC,Standard EEC box‚ molded-in transparent Ultem material
E019,AEC,Backshell adapter
,,
EE,,
EE01,DT,Shrink boot adapter‚ black
EE03,DTM,Shrink boot adapter‚ black
EE04,DTM,High temp‚ black
EE05,DT,High temp‚ enhanced seal retention (P012) on plug‚ end cap‚ black
,,
EF,,
EF01,DT,Fluorosilicone front seals‚ end cap
EF02,DT,Fluorosilicone front seals‚ latch guard end cap
,,
EK,,
EK02,DT,Plug‚ 18 cavity DT with 18 size 16 contacts‚ enhanced seal retention (P012)‚ end cap‚ “A” key is gray‚ “B” key is black‚ “C” key is green‚ “D” key is brown
,,
EP,,
EP04,DT,End cap (same as E003 mod)
EP05,DT,Latch guard end cap
EP06,DT,Plug with enhanced seal retention (P012)‚ end cap
EP07,DT,Plug with enhanced seal retention (P012)‚ black
EP08,DT,Plug with enhanced seal retention (P012)‚ end cap‚ black
EP09,DT,Plug with enhanced seal retention (P012)‚ latch guard end cap‚ black
EP10,DT‚ DTM,120 ohm terminating resistor (J1939)‚ black
EP11,DT,Plug with enhanced seal retention (P012)‚ shrink boot adapter‚ black
EP12,DT,Bussed receptacle‚ 4 and 6 way only‚ 1 buss‚ black‚ gold plated pins
EP13,DT,Bussed receptacle‚ 4 and 6 way only‚ 1 buss‚ black‚ nickel plated pins
EP14,DT,Bussed receptacle‚ 6 way‚ 2 busses‚ black‚ nickel plated pins
EP20,DT,Plug with enhanced seal retention (P012)‚ shrink boot adapter
,,
F,,
F001,HDN,Inserts within connector made of Ultem
,,
G,,
G001,DRC,Gold plated pins
G002,DRC,Outside rows of pins are gold plated and rest are tin plated
G003,DT13‚15,Gold plated pins
G004,DRC,Interface side pins are nickel plated‚ PCB side pins are tin plated
G005,DRCP,Tin plated signal pins‚ tin plated power pins
,,
GC,,
GC03,DRCP,Gold plated signal pins‚ depopulated power pins
GC05,DRCP,Tin plated signal pins‚ depopulated power pins
,,
GR,,
GR01,DTM13 (EEC headers),Snap-in DTM PCB mounted header for DTM EEC enclosure‚ 12 and 24 pins‚ gold plated pins
,,
H,,
H001,HD30,Plated with yellow chromate conversion
,,
HL,,
HL01,HD30,Dust cap plated with yellow chromate conversion‚ sash chain with eyelet for #10 screw
HL02,HD30,Adapter for cable clamp (-072) plated with yellow chromate conversion
,,
J,,
J001,HD30,Reverse cavity marking identification on grommet
J059,HD30,Reverse cavity marking identification on grommet‚ cable clamp (-059)
,,
K,,
K001,AEC,Molded-in shell marking‚ remove blue stripe‚ end cap
K003,DT16,Plug‚ 15 cavity DT with two size 12 contacts and 13 size 16 contacts‚ enhanced seal retention (P012)‚ end cap‚ black
K004,DT16,Plug‚ 18 cavity DT with 18 size 16 contacts‚ enhanced seal retention (P012)‚ end cap‚ black
,,
KP,,
KP01,DT16,Plug‚ six cavity DT with six size 16 contacts‚ enhanced seal retention (P012)‚ end cap‚ green
,,
L,,
L001,HD30,Same as -059 (cable clamp)
L003,HD30,Cable clamp adapter (-072)
L005,HD30,Cable clamp adapter (-072) without drain holes
L006,HD30,-059 modification using adapter without drain holes
L009,DTHD,Sealed flange‚ inside mount
L011,DRC,Wire router
L012,DT‚ DTP‚ DTM,Welded flange
L013,DTHD,Sealed flange‚ outside mount
L015,HDP20,Threaded adapter for backshell strain relief
L017,HDP20,Ring adapter for backshell strain relief
L018,DRB,Wire router
L020,HD30‚ HD50,Removes #10 eyelet from the dust cap chain
L024,HDP20,Wide threaded adapter for backshell strain relief
L072,HD30,Adapter ring
,,
LE,,
LE01,DT,Sealed flange‚ inside mount‚ gasket‚ end cap
LE03,DT,Sealed flange‚ outside mount‚ o-ring sold separately‚ end cap‚ NOTE: DT04-08PA-LE03 comes with shrink boot adapter and o-ring on flange
LE05,DT,Sealed flange‚ inside mount‚ gasket‚ end cap
LE06,DT,Sealed flange‚ inside mount‚ reduced diameter seals (E seal)‚ end cap
LE07,DT‚ DTP,Welded flange‚ end cap
LE08,DT,Welded flange‚ shrink boot adapter‚ gray
LE09,DT,Sealed flange‚ o-ring‚ end cap‚ black
LE10,DT,Sealed flange‚ inside mount‚ gasket‚ end cap‚ black
LE11,DT,Welded flange‚ end cap‚ black
LE12,DT,Welded flange‚ shrink boot adapter‚ black
LE13,DT,Special adapter‚ round housing‚ end cap
LE14,DT,Welded flange‚ black
LE17,DT,Receptacle with extended shell and enhanced keys (B016)‚ sealed flange‚ gasket sold separately‚ end cap‚ black
LE21,DT,Receptacle with extended shell and enhanced keys (B016)‚ sealed flange‚ reduced diameter seals (E seal)‚ end cap‚ one piece connector design‚ threaded stainless steel flange inserts
,,
N,,
N005,HD10,Receptacle with molded-in PCB pins‚ modified shell
N006,DT,Receptacle with 90° molded-in contacts
N012,DRC,Receptacle‚ one piece connector design
,,
P,,
P005,AEC,Special oversized seal on AEC Series plugs and dust caps
P006,DT‚ DTM,120 ohm terminating resistor (J1939)
P007,DT‚ DTM,Receptacle “Y” connector (J1939)
P012,DT,Plug with enhanced seal retention‚ 2-6 way are black‚ 8 and 12 way “A” key is gray‚ “B” key is black‚ “C” key is green‚ “D” key is brown
P013,DRC,Plug with bonded front seal‚ silicone adhesive
P016,DT,Bussed receptacle‚ 12 way‚ gold plated contacts
P017,DRC,Stainless steel retention clip for jackscrew
P018,DTP,Receptacle with 12 AWG wires attached
P019,DRC,Zinc chromate retention clip for jackscrew
P021,DT,Bussed receptacle‚ 6‚ 8‚ and 12 way‚ one buss‚ nickel plated pins
P026,DT,Bussed receptacle‚ 8 and 12 way‚ two busses‚ nickel plated pins
P027,DT,Bussed receptacle‚ 12 way‚ two busses‚ gold plated pins
P028,DT,Bussed receptacle‚ 8 way‚ two busses‚ nickel plated pins
P030,DT,Bussed receptacle‚ 12 way‚ four busses‚ nickel plated pins
P031,DT,Bussed receptacle‚ 12 way‚ four busses‚ gold plated pins
P032,DT,Integrated shrink boot adapter (J1939)‚ black
P060,DT,Bussed receptacle‚ 2 way‚ one buss‚ nickel plated pins
P064,HD30‚ HDP20,24-91 arrangement without internal jumper
P075,DT,Bussed receptacle‚ 12 way‚ three busses‚ nickel plated pins
P080,HD10,J1939 Type II‚ green
,,
PE,,
PE01,DT,Latch guard‚ 120 ohm terminating resistor (J1939)
,,
PP,,
PP01,DT,Plug with enhanced seal retention (P012)‚ 120 ohm terminating resistor (J1939)‚ end cap‚ black
,,
R,,
R004,DTM13,Custom enclosure header‚ 90° pins
R005,DTM13,Custom flange‚ 90° pins
R008,DTM13 (EEC headers),Snap-in DTM PCB mounted header for DTM EEC enclosure‚ 12 and 24 pins
R015,DT13 (EEC headers),Snap-in DT PCB mounted header for DT EEC enclosure‚ 12‚ 24‚ 36‚ and 48 pins
,,
RT,,
RT01,DT,Receptacle with MUR 460 diode
RT02,DT,Receptacle with Toshiba diode 3GZ41
RT03,DT,Receptacle with MUR 460 diode‚ 4 way available
RT06,DT,Receptacle with Phillips T.V.S diode 1.5KE130CA‚ green
RT25,DT,Receptacle with 27k ohm resistor‚ black
,,
#’s,,
59,HD30,Addition of threaded adapter and cable clamp assembly
72,HD30,Addition of threaded adapter
1E,HD30,Removes rivet and chain from protective dust cap
